D-Sub Rectangular Large Cable Entry EMI/RFI Shielded Backshell - Metal (Nickel / Zinc Plated)


EMI/RFI Shielded Metal 45° Large Cable Entry Backshells (Nickel / Zinc Plated)

45 Large Cable Entry EMI RFI Shielded Backshell











SME1170172223 - 9Way
9Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 9, High-D: 15, Combo-D: 5W1, 2WK2, Combo-D High-D: 8W2.

SME1170172230 - 15Way
15Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 15, High-D: 26, Combo-D: 3W3, 3WK3, 7W2, 11W1, Combo-D High-D: 19W1.


SME1170172197 - 25Way
25Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 25, High-D: 44, Combo-D: 5W5, 9W4, 13W3, 17W2, 21W1, Combo-D High-D: 15W4.

SME1170172248 - 37Way
37Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 37, High-D: 62, Combo-D: 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, Combo-D High-D: 45W2.


SME1170172379 - 37Way
37Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.720" (18.29mm) - 0.350" (8.89mm)
Size: Std-D: 37, High-D: 62, Combo-D: 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, Combo-D High-D: 45W2.

SME1170172380 - 50Way
50Way 45° EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.720" (18.29mm) - 0.350" (8.89mm)
Size: Std-D: 50, High-D: 78, Combo-D: 24W7, 36W4, 43W2, 47W1.

Please Contact us for More Options, Data Sheets, Pricing and Availability

EMI/RFI Shielded Metal Straight Large Cable Entry Backshells (Nickel / Zinc Plated) - Style A


Straight Large Cable Entry EMI RFI Shielded Backshell

SME1170172182 - 9Way
9Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.400" (10.16mm) - 0.210" (5.33mm)
Size: Std-D: 9, High-D: 15, Combo-D: 5W1, 2WK2, Combo-D High-D: 8W2.

SME1170172208 - 15Way
15Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.400" (10.16mm) - 0.210" (5.33mm)
Size: Std-D: 15, High-D: 26, Combo-D: 3W3, 3WK3, 7W2, 11W1, Combo-D High-D: 19W1.

SME1170172203 - 25Way
25Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.525" (13.33mm) - 0.230" (5.54mm)
Size: Std-D: 25, High-D: 44, Combo-D: 5W5, 9W4, 13W3, 17W2, 21W1, Combo-D High-D: 15W4.

SME1170172229 - 37Way
37Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.726" (18.44mm) - 0.350" (8.89mm)
Size: Std-D: 37, High-D: 62, Combo-D: 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, Combo-D High-D: 45W2.

SME1170172227 - 50Way
50Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.726" (18.44mm) - 0.350" (8.89mm)
Size: Std-D: 50, High-D: 78, Combo-D: 24W7, 36W4, 43W2, 47W1.

Please Contact us for More Options, Data Sheets, Pricing and Availability


EMI/RFI Shielded Metal Straight Large Cable Entry Backshells (Nickel / Zinc Plated) - Style B

Straight Large Cable Entry EMI RFI Shielded Backshell













SME1170172334 - 9Way
9Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 9, High-D: 15, Combo-D: 5W1, 2WK2, Combo-D High-D: 8W2.

SME1170172358 - 15Way
15Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 15, High-D: 26, Combo-D: 3W3, 3WK3, 7W2, 11W1, Combo-D High-D: 19W1.

SME1170172359 - 25Way
25Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 25, High-D: 44, Combo-D: 5W5, 9W4, 13W3, 17W2, 21W1, Combo-D High-D: 15W4.

SME1170172360 - 37Way
37Way Straight EMI/RFI Shielded Metal Backshell with Thumbscrews
Cable Diameter: 0.512" (13mm) - 0.138" (3.5mm)
Size: Std-D: 37, High-D: 62, Combo-D: 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, Combo-D High-D: 45W2.

Please Contact us for More Options, Data Sheets, Pricing and Availability



 Low Profile Metal 90° Large Cable Entry Backshells (Nickel / Zinc Plated)


EMI RFI Shielded Metal 90 Cable Exit Backshells

SME1170172244 - 9Way
9Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.400" (10.16mm) - 0.210" (5.33mm)
Size: Std-D: 9, High-D: 15, Combo-D: 5W1, 2WK2, Combo-D High-D: 8W2.

SME1170172262 - 15Way
15Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.400" (10.16mm) - 0.210" (5.33mm)
Size: Std-D: 15, High-D: 26, Combo-D: 3W3, 3WK3, 7W2, 11W1, Combo-D High-D: 19W1.

SME1170172263 - 25Way
25Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.540" (13.72mm) - 0.230" (5.84mm)
Size: Std-D: 25, High-D: 44, Combo-D: 5W5, 9W4, 13W3, 17W2, 21W1, Combo-D High-D: 15W4.

SME1170172340 - 25Way
25Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.540" (13.72mm) - 0.4" (10.16mm)
Size: Std-D: 25, High-D: 44, Combo-D: 5W5, 9W4, 13W3, 17W2, 21W1, Combo-D High-D: 15W4.

SME1170172264 - 37Way
37Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.726" (18.44mm) - 0.350" (8.89mm)
Size: Std-D: 37, High-D: 62, Combo-D: 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, Combo-D High-D: 45W2.

SME1170172345 - 50Way
50Way 90° Low Profile Metal Backshell with Thumbscrews
Cable Diameter: 0.726" (18.44mm) - 0.350" (8.89mm)
Size: Std-D: 50, High-D: 78, Combo-D: 24W7, 36W4, 43W2, 47W1.

Please Contact us for More Options, Data Sheets, Pricing and Availability
