Liebert GXT3-10000T230 [Emerson / UPS] - UPS system

Liebert GXT3-10000T230 [Emerson / UPS] - UPS system

$6,422.27

Liebert GXT3 10000VA On-line UPS Single Phase or Three Phase Input (Auto Selecting) - Single Phase Output - Tower UPS.

Liebert GXT3 UPS meets the need for higher power capacities in small spaces. This true on-line double conversion UPS system is available in two different 10kVA versions, and features integrated maintenance bypass, as well as optional extended battery runtime. It is available in both transformer-less and transformer-in versions. The transformer less version can work in either 1x1 or 3x1 configuration, which makes it very flexible. The isolated version is fitted with an output Isolation transformer which allows using it at 110, 120 phase to neutral or 208, 220 phase to phase voltages, for dual input with phases shifted by 180 degrees.

Flexibility:

 Automatic frequency detection

 User replaceable hot-swappable internal batteries

 Additional runtime with additional battery cabinets

 Liebert IntelliSlot™ communications port

 Multiple output possibilities (hardwired and receptacles)

 Includes Windows-based configuration program

 Built-in USB communications for use with Liebert MultiLink™ Automated Shutdown Software

 Built-in closure signals

 Emergency Power Off (EPO)

 Parallelable up to 3 units Higher Availability:

 Wider input voltage window minimizes battery use

 Internal automatic and manual bypass

 Self-diagnostics Lowest Total Cost Of Ownership:

 Standard two-year replacement warranty

 Compact footprint

 Shields batteries from heat generating electronic components

 Battery cutoff voltage to prevent from overdischarge of batteries



    Please Contact us for Datasheets, Pricing and Availability

    Specifications
    Battery Valve-regulated, nonspillable, lead acid
    Communication/Management Liebert MultiLink
    Frequency 50 - 60Hz autoselection
    Input Connection C14
    Input Voltage 220/230/240VAC
    Misc.
    Output Receptacles
    Output Voltage
    Power Rating/Capacity 10000VA
    Series GXT3
    Typical Runtime 3 minutes
    Warranty 2yrs Warranty
    x`
    Dimensions: H x W x D (mm) 300 x 675 x 800
    Form Factor Tower
    Surge Protection EN61000-4-5, Level 3, Criteria A
    Weight 105kg
